PCN-BB-0001 - Black Terminal Blocks
This PCN applies to all products supplied with black pluggable terminal blocks.
Following the release of a product to market, Brainboxes is committed to ongoing improvements in functionality, manufacturing, environmental impact and availability. As part of this commitment, our products may need to be modified or updated.
Contact Information
For any enquiries regarding the information in this PCN, please contact:
| Contact | Details |
|---|---|
| PCN ID | PCN-BB-0001-15-May-26-v1.0 |
| Brainboxes Accreditations | [email protected] |
| Phone | 0151 220 2500 |
| Address | 18 Hurricane Drive, Liverpool International Business Park, Speke, Liverpool, L24 8RL, UK |
Revision History
| ID | Title | Latest Version | Date Issued | Date Superseded | Prepared By | Approved By |
|---|---|---|---|---|---|---|
| BB-0001 | Black Terminal Blocks | 1.0 | 15-May-26 | 01-Aug-26 | JM | AW |
Description of Changes
Brainboxes has historically used either numbered or symbol-marked black pluggable terminal blocks across several of our products. Due to short-term supply constraints, we temporarily changed our bespoke symbol-marked black terminal blocks to blank terminal blocks to ensure the continued supply of products using this part.
From 15-May-26 to 31-Jul-26, this change may affect the following products:
- ED-5XX
- ES-5XX
- SW-1XX, SW-5XX, SW-6XX, SW-7XX & SW-7XXX
As of 01-Aug-26, this temporary change has been reversed, and the symbol-marked black terminal block is now used across all applicable products.
Identifying Your Terminal Block
Brainboxes has supplied three marking styles of black pluggable terminal block over time. All three are the same connector; only the printed markings differ between the styles. Depending on which products you have ordered, and when, you may receive a mixture of products with the following terminal blocks fitted:
| Type | Description |
|---|---|
| Numbered | Each connection is labelled 1 - 5 |
| Symbol-marked | Each connection is labelled with a symbol (-V, +VA, +VB, -V & FE) |
| Blank | No labelling on any connection |
All three styles are mechanically and electrically identical as the pinouts are fixed on the product itself. There is no effect on the operation, rating or reliability of the product; all three styles are fully interchangeable.
Contact Support
If you’re unsure about the wiring connections of your terminal block, please refer to the pinouts listed on the product label or in the product documentation, or contact [email protected] and we’ll be happy to help.
