Track configuration drift on your devices with BB-Eco

When a device's live configuration diverges from the last configuration you blessed, that's drift: someone fixed a baud rate by hand, a web-UI visit saved an accidental change, a replacement unit came in with factory settings. BB-Eco notices for you: it records a baseline for every device it manages and flags any difference between that baseline and the live device.

Before you start​

Baselines are automatic​

The first time BB-Eco sees a device, it captures the device's configuration as its baseline, and you'll briefly see Capturing initial configuration… in the Configuration Status section of the Info tab. No setup required. From then on, BB-Eco re-reads the device's configuration in the background and compares.

Spot drift in the dashboard​

A drifted device shows a drift indicator on its dashboard card (next to the MAC address), so a whole fleet is scannable at a glance. Open the device's detail panel for the specifics. Each drifted setting renders as the struck-through baseline value, an arrow, and the live value:

In a single drifted row, left of the arrow is what the baseline recorded and right is what the device says now:

Detail panel Name row showing 'Line-A-Sensor-12' struck through, an arrow, and 'Line A Sensor 12' in amber: the device's live name no longer matches its captured baseline

The Configuration Status section lists each change since the baseline:

Configuration Status close-up, '3 changes since baseline': Network > Gateway Address 192.168.1.1 to 192.168.1.254, Device > Device Name Line-A-Sensor-12 to Line A Sensor 12, Network > Web Server Port 80 to 8080; each baseline value is struck through and the device's value is in amber

When nothing has changed, the section simply reads In sync with baseline.

Verify from the CLI​

bb-eco template diff compares a live device against any template file, whether the exported baseline or a fleet standard from Git:

bb-eco template diff 192.168.1.107 es-522-baseline.json
Device is compliant — 32 field(s) match template.

And when something has drifted:

Section Key Template Actual Status
------- ----------- ----------- ------------------------------------ ------
device device.name Line3-ES522 Brainboxes ES-522 Ethernet to Serial DRIFT

DRIFTED: 1 field(s) differ, 31 match.

Fields set to null in the template are "don't care" and never count as drift.

Decide: revert or re-baseline​

Drift itself isn't the problem; undecided drift is. Two buttons on the Info tab map to the two decisions:

DecisionWhenIn the appIn the CLI
Revert: the template is rightThe change was unintentionalApply Template with your baseline filebb-eco template apply (use --dry-run first)
Re-baseline: the device is rightThe change was deliberateRefresh baselinebb-eco template export, commit the diff to Git

After you intentionally change settings, refresh the baseline straight away, so future drift is tracked from the new state, not the old one.

Next step​

One device is a habit; a fleet is a workflow. Detect configuration drift across your fleet covers scheduled CLI audits, CI integration, and site-specific template overrides.
